WJ型卷筒用球面滚子联轴器

WJ起重卷筒联轴器是一种球面滚子联轴器,有带联接法兰的外套,球面滚子,半联轴器及内外盖板及密封系统组成,能够传递较大扭矩及承受径向载荷。

WJ型卷筒用球面滚子联轴器
WJ型卷筒用球面滚子联轴器

WJ联轴器,WJ卷筒联轴器,球面滚子卷筒用联轴器

WJ系列卷筒用联轴器的基本参数

型号公称转矩许用径向dDD-1D2D3n-d1d2d3SLl1l2l3l4l5l6l7α/(°)rC磨损刻度 M1转动惯量质量
Tn/kN·m力/kN内花键(H6)螺栓(M6)(K6)(h9)I/g·mm/kg
WJ1414.5INT16Z×2.5m250220160856-14M1235452208042512242230186021.640.0612
INT17Z×2.5m384811
WJ2516.5INT17Z×2.5m280250180906-14M1238482508042512242230186021.640.1118
INT15Z×3m405017
WJ37.118.5INT15Z×3m320280200956-18M164050280844551525223022602.51.640.1820.1
INT18Z×3m5060219.8
WJ4920INT18Z×3m3403002201306-18M165060300924551525223030602.5240.2526.2
INT22Z×3m6070352526.3
WJ51431INT22Z×3m3603202401506-18M166070320924551525223525602.5260.3331.6
INT27Z×3m708597402.530.9
WJ61835INT27Z×3m3803402601606-18M167085340974551525224025602.52.560.4436.5
INT18Z×5m80100127375037.5
WJ722.438.5INT18Z×5m4003602801706-18M1680100360127672515333750256032.560.5844.9
INT22Z×5m100120137553042.9
WJ82842INT22Z×5m4203803102006-18M16100120380137773515333755306032.560.8556
INT26Z×5m1201401577035354
WJ935.549INT26Z×5m4504003402306-22M2012014040015787402028377037603361.2972
INT30Z×5m140160167754070
WJ1071115INT30Z×5m5505004202806-22M2014016050016795432038377540603383.4124
INT34Z×5m1601801828545120
WJ11112125INT34Z×5m5805304503008-22M2016018053018295432038378545403384.08136
INT38Z×5m180200192954132
WJ12180150INT38Z×5m6506005303608-22M20180200580192120632533379545403487.23190
INT26Z×8m190222207105187
WJ13315250INT26Z×8m68063056040024-22M201902226002071206325353710545104489.66228
INT30Z×8m2202542221205220
WJ14400300INT30Z×8m71066060044024-26M2422025464022214068354337120451045814.5290
INT34Z×8m250286237135285
WJ15500340INT34Z×8m78073067050024-26M2425028670023716088354337135451045823.9390
INT38Z×8m28031826215055382
WJ16630380INT38Z×8m85080073055024-26M24280318760262180108354337150551045834.2476
INT44Z×8m320366287170606466
WJ17800450INT44Z×8m95090084063024-26M24320366860287200118455537170601046873.3766
INT50Z×8m360420352522208716
